Part 9: Performance Tuning

ClickHouse is fast out of the box, but if you’re querying petabytes of data, “fast out of the box” isn’t enough. To get sub-second response times on massive datasets, you need to master advanced tuning: choosing the perfect sorting key, adding skipping indexes, configuring column-level codecs, and reading execution plans. Let’s optimize.

Sorting Keys: The Foundation of Performance

As we discussed in Part 3, ClickHouse doesn’t use B-Tree indexes. It physically sorts data files on disk based on the ORDER BY clause.

If your table is ordered by (customer_country, timestamp), ClickHouse sorts the rows first by country, and then by timestamp within each country.

Multi-Column Sort Visualization

Imagine the physical rows written to disk:

Row 1: CA | 2023-10-01 12:00:00
Row 2: CA | 2023-10-01 13:00:00
Row 3: US | 2023-10-01 11:00:00
Row 4: US | 2023-10-01 12:00:00

Because the rows are sorted, the primary index (primary.idx) stores the values for every 8,192nd row. If you query WHERE customer_country = 'US', the sparse index tells ClickHouse exactly which mark range to skip, letting it ignore the Canadian rows entirely.

ELI5: What is sorting and indexing in multidimensional space? How does it differ from sorting in a flat database? Read ELI5: Z-Ordering for the breakdown.

Data Skipping Indexes (Secondary Indexes)

What happens if you want to query a column that is not in your ORDER BY key?

For example, your table is sorted by (customer_country, timestamp), but users want to search for a specific user_agent. Normally, ClickHouse would have to do a full scan of the user_agent column file on disk.

To prevent this, you can add a Data Skipping Index (also known as a secondary index).

Unlike primary keys, which sort the data, skipping index files store aggregated information about column values for each Mark Range (every 8,192 rows). When a query runs, ClickHouse checks the skipping index file to see if the search term exists in that mark range. If it doesn’t, it skips reading the corresponding data blocks.

Distracted Boyfriend Skipping Index Data engineers choosing bloom_filter skipping indexes over doing full table scans on high-cardinality text columns.

The Three Index Types:

minmax: Stores the minimum and maximum values of the column for each mark range. Best for dates, timestamps, or sequential IDs.
set(N): Stores a set of unique values (up to N values) for each mark range. Best for columns with low cardinality (like status codes, category IDs).
bloom_filter(false_positive_rate): Uses a mathematical Bloom filter to check if a value is present. Best for high-cardinality columns (like user IDs, URLs, search terms).

Adding and Materializing a Skipping Index

Let’s add a Bloom filter index to a user_agent column:

-- 1. Define the index on the table
ALTER TABLE orders_flat
ADD INDEX idx_user_agent user_agent TYPE bloom_filter(0.01) GRANULARITY 1;

-- 2. Materialize the index for existing historical files
ALTER TABLE orders_flat
MATERIALIZE INDEX idx_user_agent;

TYPE bloom_filter(0.01): Creates a Bloom filter with a 1% false positive rate.
GRANULARITY 1: Tells ClickHouse to write one index mark for every single primary index mark range (every 8,192 rows). If granularity was set to 2, it would write one index mark for every 16,384 rows.

For details, consult the ClickHouse Skipping Indexes Docs.

Compression Codecs: Squeezing the Disk

ClickHouse supports column-level compression codecs. By choosing the right codec for the right data type, you can dramatically reduce disk space and speed up queries (because less compressed data needs to be read from disk).

Codec	Target Data Type	How it Works
`DoubleDelta`	Monotonically increasing values (Timestamps, Auto-increment IDs)	Computes differences between adjacent differences. Reduces sorted series to tiny integers.
`Gorilla`	Floating-point values (Sensor data, stock prices)	Exploits XOR patterns in successive float representations.
`T64`	Integers with small ranges	Truncates unused high bits of integer columns.
`ZSTD(level)`	Text, JSON, high-cardinality strings	Standard high-ratio compression algorithm.

Example of applying combined codecs:

CREATE TABLE metric_snapshots (
    timestamp DateTime CODEC(DoubleDelta, LZ4),
    device_id UInt32 CODEC(T64, LZ4),
    temperature Float64 CODEC(Gorilla, ZSTD(3))
) ENGINE = MergeTree()
ORDER BY (device_id, timestamp);

Read the ClickHouse Codecs Guide to match data shapes to codecs.

Query Profiling with `EXPLAIN`

To verify if your partitions, sorting keys, and skipping indexes are actually working, prep your query with EXPLAIN.

EXPLAIN plan = 1, indexes = 1
SELECT count()
FROM orders_flat
WHERE customer_country = 'US' AND user_agent LIKE '%Chrome%';

What to Look For in the Output:

Expression ((Projection + Before ORDER BY))
  Filter (WHERE)
    ReadFromMergeTree (orders_flat)
    Indexes:
      PrimaryKey
        Keys: customer_country
        Condition: (customer_country = 'US')
        Parts: 3/10
        Granules: 15/150
      Skip
        Indexes: idx_user_agent
        Condition: (user_agent LIKE '%Chrome%')
        Parts: 1/3
        Granules: 2/15

PrimaryKey -> Parts: 3/10: Shows that partition pruning successfully skipped 7 out of 10 disk parts.
PrimaryKey -> Granules: 15/150: Shows the primary index successfully skipped 135 out of 150 granules.
Skip -> Granules: 2/15: Shows the idx_user_agent skipping index successfully skipped 13 of the remaining 15 granules, meaning ClickHouse only read 2 data blocks from disk to answer the query.

If your explain plan shows Granules: 150/150, your indexing strategy isn’t working, and ClickHouse is doing a full table scan.

For deep pipeline profiling, read the ClickHouse EXPLAIN Statement Docs.

Now that we have tuned our single-node performance, we are ready to scale horizontally. In the final part, we’ll talk about Sharding, Replication, and Distributed Clusters.
