Part 3: The MergeTree Family

If ClickHouse is a race car, the MergeTree engine is its V12 engine. It is the foundation of almost all high-performance tables in ClickHouse. If you don’t understand how MergeTree stores, sorts, and merges data on disk, you will write slow tables and query them like a novice. Let’s lift the hood and look at the physical files.

B-Tree vs. Sparse Index: The Core Paradigm Shift

In standard OLTP databases (like PostgreSQL), indexes are built using B-Trees. A B-Tree index contains pointers to the exact physical location of every single row. If you query WHERE id = 42, the B-Tree tells the database precisely which disk block to read.

This is great for transaction processing but terrible for analytics. If you have 500 million rows, a B-Tree index becomes massive, consuming gigabytes of RAM.

ClickHouse does not use B-Trees. It uses a Sparse Index.

Instead of pointing to individual rows, the primary key in ClickHouse sorts the data on disk and creates an index entry only once every 8,192 rows (this block is called a Mark Range).

Pam's "They're the same picture" meme Data engineers showing their DBAs a ClickHouse primary key vs a Postgres primary key. “It’s the same name, but one doesn’t eat all your RAM for breakfast.”

ELI5: What is index granularity and sparse indexing? Imagine sorting letters into bundles instead of filing them one by one. Check out ELI5: The MergeTree Engine for the full analogy.

What Happens on Disk?

Let’s look at what ClickHouse writes to disk when you create a table and insert data.

Creating the Table

CREATE TABLE hits (
    timestamp DateTime,
    user_id UInt64,
    url String,
    event_type Enum('view' = 1, 'click' = 2)
) ENGINE = MergeTree()
PARTITION BY toYYYYMM(timestamp)
ORDER BY (timestamp, user_id)
SETTINGS index_granularity = 8192;

When you write data to this table, ClickHouse creates a new directory inside /var/lib/clickhouse/data/default/hits/ for each insert batch. Let’s inspect the files in one of these directories:

primary.idx: The sparse index file. It contains the primary keys (timestamp, user_id) for every 8,192nd row in the part. Since it only contains 1 out of every 8,192 values, it is tiny and fits entirely in RAM.
[column].bin: The compressed binary data for each column (e.g., url.bin, user_id.bin).
[column].mrk2: The “mark” files. These serve as a map. They translate the indexes in primary.idx into physical file offsets in [column].bin so ClickHouse knows exactly where to jump to start reading.

If you run SELECT COUNT(url) FROM hits WHERE timestamp >= '2023-10-01 00:00:00', ClickHouse:

Searches primary.idx in memory to find the Mark Ranges that match the timestamp.
Reads the url.mrk2 file to locate the exact offset in url.bin.
Opens url.bin at that offset, decompresses the blocks, and aggregates the values.
It never opens or reads user_id.bin or event_type.bin.

The Magic of Partitioning

Partitioning is the process of physically splitting your table files into separate directories on disk based on a column or expression.

In our schema, we partitioned by month: PARTITION BY toYYYYMM(timestamp).

ELI5: What is partitioning? Think of it like sorting your receipts into yearly drawers and monthly folders so you don’t have to scan a single giant box in your attic. Check out ELI5: Database Partitioning for the breakdown.

If you run SELECT * FROM hits WHERE timestamp BETWEEN '2023-10-01' AND '2023-10-15', ClickHouse checks the partition key and only searches directories matching 202310. It completely skips the folders for 202309, 202308, and so on. This is called Partition Pruning.

For official partitioning settings and caveats, consult the ClickHouse Partitioning Documentation.

The Directory Naming Rule

When data is written, ClickHouse writes folders named like this:

202310_1_1_0
202310_2_2_0

Let’s break down 202310_1_1_0:

202310: The partition ID (October 2023).
1: The minimum block number of the insert.
1: The maximum block number of the insert.
0: The mutation version (incremented if the data is mutated or updated in place).

The Merge Process

Every time you execute an INSERT statement, ClickHouse creates a new physical folder (part) on disk.

If you insert 1 row per second, you will quickly end up with thousands of folders. Opening thousands of folders and files to answer a query will kill performance (often leading to the Too many parts error).

To prevent this, ClickHouse’s background processes merge these folders.

graph TD
    A["Part A (202310_1_1_0)"] --> D["Merged Part (202310_1_2_1)"]
    B["Part B (202310_2_2_0)"] --> D
    D --> E["Merged in Background"]

During a merge:

ClickHouse reads two or more adjacent parts for the same partition.
It combines the rows, keeping them sorted by the ORDER BY key.
It writes a brand-new folder, e.g., 202310_1_2_1.
It marks the old folders (202310_1_1_0 and 202310_2_2_0) as inactive and deletes them after a short delay (usually 10 minutes).

Because the parts are already sorted, merging them is an extremely efficient external merge sort operation. It does not stress the CPU, but it does consume disk I/O.

Best Practices for MergeTree Schemas

Keep the Partition Cardinality Low: Do not partition by date down to the day or by user_id. Aim for less than 1,000 total partitions in a table. Partitioning by month (toYYYYMM(timestamp)) is the golden standard.
Order Matters in Primary Keys: Keep your primary key (ORDER BY) small (typically 2-4 columns). Place the columns you filter by most frequently first. Order from lowest cardinality to highest cardinality. For example, ORDER BY (event_type, user_id, timestamp) is often much faster than placing timestamp first if you always filter by event_type first.

For further reference, read the Official ClickHouse MergeTree Engine Docs.

Now that you know how the engine writes files, we’ll look at how to model complex structures and denormalize data in Part 4.
